Gocator Line Profile Sensors: User Manual
Gocator Device Files • 389
Element Type Description
Measurements\GlobalAngle Bounding Box tool
measurement
GlobalAngle measurement
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature.
Features\CornerPoint GeometricFeature CornerPoint PointFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Bounding Box Tool Measurement
ProfileBridgeValue
A ProfileBridgeValue element defines settings for a profile bridge value tool and one or more of its
measurements.
This measurement is only available on Gocator 2342 sensors.
Element Type Description
Name String Tool name.
Features
Collection Not used.
Source 32s Profile source.
ProfileBridgeValue Child Elements
