Gocator Line Profile Sensors: User Manual
Gocator Device Files • 388
Element Type Description
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
ProfileBoundingBox
A ProfileBoundingBox element defines settings for a profile bounding box tool and one or more of its
measurements.
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See ProfileBoundingBox above.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Measurement region.
Measurements\X Bounding Box tool
measurement
X measurement.
Measurements\Z Bounding Box tool
measurement
Z measurement.
Measurements\Width Bounding Box tool
measurement
Width measurement.
Measurements\Height Bounding Box tool
measurement
Height measurement.
Measurements\GlobalX Bounding Box tool
measurement
GlobalX measurement
Measurements\GlobalY Bounding Box tool
measurement
GlobalY measurement
ProfileBoundingBox Child Elements
