LMI Technologies Master 800 User Manual

Gocator Line Profile Sensors: User Manual
583
Specifications
The following sections describe the specifications of Gocator sensors and connectors, as well as Master
hubs.
Sensors
The following sections provide the specifications of Gocator sensors.
Gocator 2100 & 2300 Series
The Gocator 2100 and 2300 series consists of the following models:
MODEL 2320 2x30 2x40 2342 2x50 2x70 2375 2x80
Data Points /
Profile
1280 640 / 1280 640 / 1280 1280 640 / 1280 640 /1280 1280 640 / 1280
Linearity Z
(+/- % of MR)
0.01 0.01 0.01 0.01 0.01 0.04 0.05 0.04
Resolution Z
(mm)
0.0018 -
0.0030
0.006 -
0.014
0.013 -
0.037
0.015 -
0.040
0.019 -
0.060
0.055 -
0.200
0.154 - 0.56 0.092- 0.488
Resolution X
(mm)
(Profile Data
Interval)
2100 series n/a
0.088 -
0.150
0.19 - 0.34 n/a 0.3 - 0.6 0.55 - 1.10 n/a
0.75 - 2.20
2300 series 0.014 - 0.021
0.044 -
0.075
0.095 -
0.170
0.095 -
0.170
0.150 -
0.300
0.275 -
0.550
0.27 - 0.80
0.375 - 1.100
Repeatability Z
(µm)
0.4 0.8 1.2 1.2 2 8 n/a 12
Clearance
Distance (CD)
(mm)
40 90 190 190 300 400 650 350
Measurement
Range (MR)
(mm)
25 80 210 210 400 500 1350 800
Field of View
(FOV) (mm)
18 - 26 47 - 85 96 - 194 64 - 140 158 - 365 308 - 687 345 - 1028 390 - 1260
Recommended
Laser Class
2M 2M 3R 3R 3R 3B 3B-N 3B
