Gocator Line Profile Sensors: User Manual
Development Kits • 538
Data Type Description
GoBoundingBoxMatchMsg Represents a message containing bounding box based part matching results.
GoDataMsg
Represents a base message sourced from the data channel. See GoDataSet Type below
for more information.
GoEdgeMatchMsg Represents a message containing edge based part matching results.
GoEllipseMatchMsg Represents a message containing ellipse based part matching results.
GoExposureCalMsg Represents a message containing exposure calibration results.
GoMeasurementMsg Represents a message containing a set of GoMeasurementData objects.
GoProfileIntensityMsg Represents a data message containing a set of profile intensity arrays.
GoProfileMsg
Represents a data message containing a set of profile arrays.
GoRangeIntensityMsg Represents a data message containing a set of range intensity data.
GoRangeMsg Represents a data message containing a set of range data.
GoResampledProfileMsg Represents a data message containing a set of resampled profile arrays.
GoSectionMsg Represents a data message containing a set of section arrays.
GoSectionIntensityMsg Represents a data message containing a set of profile intensity arrays.
GoStampMsg Represents a message containing a set of acquisition stamps.
GoSurfaceIntensityMsg Represents a data message containing a surface intensity array.
GoSurfaceMsg Represents a data message containing a surface array.
GoVideoMsg Represents a data message containing a video image.
Refer to the GoSdkSamples sample code for examples of acquiring data using these data types.
See Setup and Locations on page 535 for more information on the code samples.
GoDataSet Type
Data are passed to the data handler in a GoDataSet object. The GoDataSet object is a container that can
contain any type of data, including scan data (profiles, sections, or surfaces), measurements, and results
from various operations. Data inside the GoDataSet object are represented as messages.
The following illustrates the content of a GoDataSet object of a profile mode setup with two
measurements. The content when using a surface mode setup is identical, except that a GoSurfaceMsg is
sent instead of a GoProfileMsg.
