Gocator Line Profile Sensors: User Manual
Gocator Device Files • 418
Element Type Description
Measurements\Major Ellipse tool
measurement
Major measurement.
Measurements\Minor Ellipse tool
measurement
Minor measurement.
Measurements\Ratio Ellipse tool
measurement
Ratio measurement.
Measurements\ZAngle Ellipse tool
measurement
ZAngle measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
Features\MajorAxisLine GeometricFeature MajorAxisLine LineFeature
Features\MinroAxisLine GeometricFeature MinorAxisLine LineFeature
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Ellipse Tool Measurement
SurfaceHole
A SurfaceHoleelement defines settings for a surface hole tool and one or more of its measurements.
