Gocator Line Profile Sensors: User Manual
Gocator Device Files • 419
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See SurfaceHole on the previous page.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
NominalRadius 64f Nominal radius (mm).
RadiusTolerance 64f Radius tolerance (mm).
PartialDetectionEnabled Boolean
Setting to enable/disable partial detection:
0 – Disable
1 – Enable
DepthLimitEnabled Boolean Setting to enable/disable depth limit:
0 – Disable
1 – Enable
DepthLimit 64f The depth limit relative to the surface. Data below this limit
is ignored.
RegionEnabled Boolean
Setting to enable/disable region:
0 – Disable
1 – Enable
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
SurfaceHole Child Elements
