Gocator Line Profile Sensors: User Manual
Gocator Device Files • 366
Plate
Element Type Description
Height 64f Plate height (mm).
HoleCount 32u Number of holes.
RefHoleDiameter 64f Diameter of reference hole (mm).
SecHoleDiameter 64f Diameter of secondary hole(s) (mm).
Plate Child Elements
Devices / Device
Element Type Description
@index 32u Ordered index of devices in device list.
@role 32s
Sensor role:
0 – Main
1 – Buddy
Layout
Layout
Multiplexing bank settings.
DataSource 32s
Data source of device output (read-only):
0 – Top
1 – Bottom
2 – Top Left
3 – Top Right
XSpacingCount 32u Number of resampled points along X (read-only).
YSpacingCount 32u Number of resampled points along Y (read-only).
ActiveArea
Region3D
Active area. (Contains min and max attributes for each element.)
TransformedDataRegion
Region3D
Active area after transformation (read-only).
FrontCamera
Window
Front camera window (read-only).
BackCamera
Window
Back camera window (read-only).
BackCamera.used Bool Whether or not this field is used.
PatternSequenceType 32s
The projector pattern sequence to display when a projector equipped
device is running. The following types are possible:
-1 – None
0 – Default
100 – Nine Lines
PatternSequenceType.optio
ns
32s List of available pattern sequence types.
PatternSequenceType.used
Bool Whether or not this field is used.
PatternSequenceCount 32u Number of frames in the active sequence (read-only).
ExposureMode 32s
Exposure mode:
Devices / Device Child Elements
