Gocator Line Profile Sensors: User Manual
Gocator Device Files • 378
Element Type Description
Acceptance/Minor/Max 64f Maximum minor length (mm).
Acceptance/Minor/Tolerance 64f Minor acceptance tolerance value
Acceptance/Minor/Tolerance.dep
recated
Bool Whether this tolerance field is deprecated
X 64f X value
X.deprecated Bool Whether this X field is deprecated
Y 64f Y value
Y.deprecated Bool Whether this Y field is deprecated
Width 64f Width value
Width.deprecated Bool Whether this width field is deprecated
Length 64f Length value
Length.deprecated Bool Whether this length field is deprecated
Replay
Contains settings related to recording filtering.
RecordingFiltering
Element Type Description
ConditionCombineType 32s
0 – Any: If any enabled condition is satisfied, the current frame is
recorded.
1 – All: All enabled conditions must be satisfied for the current frame to
be recorded.
Conditions Collection
A collection of AnyMeasurement, AnyData, or Measurement
conditions.
RecordingFiltering Child Elements
Conditions/AnyMeasurement
Element Type Description
Enabled Bool Indicates whether the condition is enabled.
Result 32s
The measurement decision criteria to be included in the filter. Possible
values are:
0 – Pass
1 – Fail
2 – Valid
3 – Invalid
Conditions/AnyMeasurement Elements
