Gocator Line Profile Sensors: User Manual
Gocator Device Files • 417
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
SurfaceEllipse
A SurfaceEllipse element defines settings for a surface ellipse tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See SurfaceEllipse above.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
AsymmetryDetectionType 32s
Determine whether to use asymmetry detection and if
enabled, which dimension would be the basis of detection.
The possible values are:
0 – None
1 – Major
2 – Minor
SurfaceEllipse Child Elements
