Gocator Line Profile Sensors: User Manual
Gocator Device Files • 416
Element Type Description
Parameters\FillValue
GdkParamFloat
Fill value value.
Parameters\FillValue.units String Units of fill value (e.g.: mm).
Parameters\IntensityFillValue
GdkParamFloat
Intensity fill value value.
Parameters\IntensityFillValue.
min
8u Intensity fill value minimum value.
Parameters\IntensityFillValue.
max
8u Intensity fill value maximum value.
Parameters\RenderDetail
GdkParamBool
Render detail Boolean.
Measurements\Measurement
@type=X
EdgeMeasurement
Base X measurement.
Measurements\Measurement
@type=Y
Edge Measurement Base Y measurement.
Measurements\Measurement
@type=Z
Edge Measurement Base Z measurement.
Measurements\Measurement
@type=ZAngle
Edge Measurement Base ZAngle measurement.
Measurements\Measurement
@type=Height
Edge Measurement Base Height measurement.
Features\Feature
@type=EdgeLine
Gdk Feature
EdgeLine line feature.
Features\Feature
@type=CenterPoint
Gdk Feature CenterPoint point feature.
@id 32s
Measurement ID. Optional (measurement disabled if not
set).
@type String Type name of measurement.
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
Edge Measurement Child Elements
