Gocator Line Profile Sensors: User Manual
Gocator Device Files • 438
Digital0 and Digital1
The Digital0 and Digital1 elements define settings for the Gocator's two digital outputs.
Element Type Description
Event 32s
Triggering event:
0 – None (disabled)
1 – Measurements
2 – Software
3 – Alignment state
4 – Acquisition start
5 – Acquisition end
SignalType 32s
Signal type:
0 – Pulse
1 – Continuous
ScheduleEnabled Bool Enables scheduling.
PulseWidth 64f Pulse width (µs).
PulseWidth.min 64f Minimum pulse width (µs).
PulseWidth.max 64f Maximum pulse width (µs).
PassMode 32s
Measurement pass condition:
0 – AND of measurements is true
1 – AND of measurements is false
2 – Always assert
Delay 64f Output delay (µs or mm, depending on delay domain defined below).
DelayDomain 32s
Output delay domain:
0 – Time (µs)
1 – Encoder (mm)
Inverted Bool Whether the sent bits are flipped.
Measurements 32u (CSV) Selected measurement sources.
Measurements.options 32u (CSV) List of available measurement sources.
Digital0 and Digital1 Child Elements
Analog
The Analog element defines settings for analog output.
The range of valid measurement values [DataScaleMin, DataScaleMax] is scaled linearly to the specified
current range [CurrentMin, CurrentMax].
Only one Value or Decision source can be selected at a time.
