Gocator Line Profile Sensors: User Manual

Gocator Web Interface • 210

Measurements and Settings

Measurement Illustration

Bridge Value

Determines the bridge value of the profile.

Angle

Determines the angle of the line fitted to the profile.

When Normalize Tilt is unchecked, the measurement

always returns 0.

Measurements
