Gocator Line Profile Sensors: User Manual
Gocator Device Files • 432
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Parameters\WidthAbsolute
(Width measurement only)
GdkParamBool Absolute width enabled boolean.
Parameters\LengthAbsolute
(Length measurement only)
GdkParamBool Absolute length enabled boolean.
Parameters\HeightAbsolute
(Height measurement only)
GdkParamBool Absolute height enabled boolean.
Tool
A Tool element of type FeatureIntersect defines settings for a feature intersection tool and one or more
of its measurements.
Element Type Description
@type String Type name of the tool.
@version String Version string for custom tool.
Name String Tool name.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Parameters\Line
GdkParamGeometricFeature
Line feature input.
Parameters\RefLine GdkParamGeometricFeature Reference line feature input.
Measurements\Measurement
@type=\X
Intersect Measurement
X measurement.
Measurements\Measurement
@type=Y
Intersect Measurement Y measurement.
Tool Child Elements
