Gocator Line Profile Sensors: User Manual
Gocator Device Files • 415
Element Type Description
Parameters\Region3
GdkParamSurfaceRegi
on3d
Fourth edge region parameter.
Parameters\SearchDirection
GdkParamInt
Direction of search.
Parameters\FixedAngleValue GdkParamFloat Fixed angle value
Parameters\FixedAngleValue.u
nits
String Units of fixed angle (e.g.: deg)
Parameters\UseFixedAngle GdkParamBool Use fixed angle boolean.
Parameters\PathSpacing GdkParamFloat Path spacing value
Parameters\PathSpacing.units String Units of path spacing (eg: mm)
Parameters\PathWidth
GdkParamFloat
Path width.
Parameters\PathWidth.units String Units of path width (e.g.: mm).
Parameters\SelectEdge
GdkParamInt
Edge selection type. Is either:
0 – Best
1 – First
2 – Last
Parameters\EdgeDirection
GdkParamInt
Edge direction type. Is either:
0 – Rising
1 – Falling
2 – Rising or Falling
Parameters\EdgeThreshold
GdkParamFloat
Edge threshold value.
Parameters\EdgeThreshold.uni
ts
String Units of edge threshold (e.g.: mm).
Parameters\IntensityThreshold
GdkParamFloat
Intensity threshold value.
Parameters\UseRelativeThresh
old
GdkParamBool Use relative threshold boolean
Parameters\RelativeThreshold GdkParamFloat Relative threshold value.
Parameters\RelativeThreshold.
units
String Units of relative threshold (e.g.: %)
Parameters\EdgeSmoothing
GdkParamFloat
Edge smoothing value.
Parameters\EdgeSmoothing.u
nits
String Units of edge smoothing (e.g.: mm).
Parameters\EdgeWidth
GdkParamFloat
The step width.
Parameters\EdgeWidth.units String Units of edge (e.g.:mm).
Parameters\EdgeMaxGap
GdkParamFloat
Edge max gap value.
Parameters\EdgeMaxGap.units String Units of edge max gap (eg: mm).
Parameters\FillBackground
GdkParamBool
Fill background boolean
