Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 217
Parameter Description
Stream The data that the tool will apply measurements to.
In Surface mode, this setting is only displayed when a
section is defined on the surface data.
For more information on sections, see Sections on page 174.
Feature 1
Feature 2
The Feature 1 and Feature 2 settings represent the two
features the tool uses to perform measurements. For each,
one of the following:
l Max Z
l Min Z
l Max X
l Min X
l Corner
l Average
l Rising Edge
l Falling Edge
l Any Edge
l Top Corner
l Bottom Corner
l Left Corner
l Right Corner
l Median
To set the region of a feature, adjust it graphically in the
data viewer, or expand the feature using the expand
button ( ) and enter the values in the fields. For more
information on regions, see Regions on page 184.
Absolute
(Width and Height measurements only)
Determines if the result will be expressed as an absolute or
a signed value.
Filters The filters that are applied to measurement values before
they are output. For more information, see Filters on page
192.
Decision The Max and Min settings define the range that determines
whether the measurement tool sends a pass or fail decision
to the output. For more information, see Decisions on page
191.
Anchor Description
X or Z Lets you choose the X or Z measurement of another tool to
use as a positional anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 194.
