Gocator Line Profile Sensors: User Manual
Gocator Device Files • 393
Element Type Description
Name String Tool name.
Features
Collection Not used.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RefFeature
ProfileFeature
Reference measurement region.
Feature
ProfileFeature
Measurement region.
Measurements\Width Dimension tool
measurement
Width measurement.
Measurements\Height Dimension tool
measurement
Height measurement.
Measurements\Distance Dimension tool
measurement
Distance measurement.
Measurements\CenterX Dimension tool
measurement
CenterX measurement.
Measurements\CenterZ Dimension tool
measurement
CenterZ measurement.
ProfileDimension Child Elements
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
Dimension Tool Measurement
