Gocator Line Profile Sensors: User Manual
Gocator Device Files • 408
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See SurfaceBoundingBox on the previous page.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
ZRotationEnabled Boolean Setting to enable/disable rotation of bounding box
AsymmetryDetectionType 32s
Determine whether to use asymmetry detection and if
enabled, which dimension would be the basis of detection.
The possible values are:
0 – None
1 – Length
2 – Width
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
Measurements\X Bounding Box tool
measurement
X measurement.
Measurements\Y Bounding Box tool
measurement
Y measurement.
Measurements\Z Bounding Box tool
measurement
Z measurement.
Measurements\Width Bounding Box tool
measurement
Width measurement.
Measurements\Length BoundingBoxMeasure Length measurement
SurfaceBoundingBoxChild Elements
