Gocator Line Profile Sensors: User Manual
Gocator Device Files • 427
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See Feature Child Elements on page 429.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
StudRadius 64f Radius of stud (mm).
StudHeight 64f Height of stud (mm).
BaseHeight 64f Height of stud’s base.
TipHeight 64f Height of stud’s tip.
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions that are to be used.
(
Advanced
tab.)
RefRegions (Collection) Reference regions. Contains up to four RefRegion elements
of type SurfaceRegion2D. (Advanced tab.)
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction (Advanced tab):
0 – Auto Set
1 – Custom
SurfaceStudChild Elements
