5-10 P/N 9-500-0255
Service Manual
Chapter 5: Maintenance—General
Troubleshooting
3.3 System Data Retrieval
The Affinity System provides the Service Engineer with the capability to download/upload
calibration data and the Alert Codes Log to a laptop computer with a Terminal Emulation
Program (such as HyperTerm). This allows the Service Engineer to print or append this data
as needed.
In order download this information, a Null-Modem, 9 pin to 25 pin Adapter, approximately
6 feet, is required (Tandy Radio Shack Catalog #950-0188, or equivalent).
1. Connect the laptop computer to the Affinity System using the Null-Modem Cable as
shown in Figure 5-1.
85 BOOST_TUBEHEAD_COMM_ERROR SYSTEM ERROR During boost, Host board is unable to
communicate with Tubehead Controller.
86 AF_EXPOSURE_TUBEHEAD_COMM_ERRO
R
SYSTEM ERROR During Auto-Filter Exposure, Host board
is unable to communicate with Tube-
head Controller.
90 FLASHER_COMM_ERROR AUTO ID Flasher does not respond.
92 PRINTER_NO_PAPER_ERROR PRINT NO PAPER
93 PRINTER_OFF_LINE_ERROR PRINT OFF LINE
95 INTERLOCK_STATUS_ERROR INTERLOCKS Interlock circuit hardware reports an
error.
Table 5-2: Affinity Series Alert Messages
No. Alert Name Alert Messages Comment
Table 5-3: Null-Modem, 9-pin to 25-pin Adapter Connections
9-pin, Female, DB-9 25-pin, Male, DB-25
Signal From To Signal
RX Data 2 2 TX Data
TXData33RXData
S-Ground 5 7 S-Ground
CTS75CTS
RTS84RTS
