6-28 P/N 9-500-0255
Service Manual
Chapter 6: Maintenance—Remove and Replace Procedures
C-Arm Components—Remove and Replace
Use the following legend and illustration as a guide for parts identification on the
Compression Device (refer to Figure 6-17).
Legend for Figure 6-17
1. Compression Motor & Brake
Assembly
2. Compression Clutch & Clutch
Brake Assembly
3. Compression Force & Thickness
Display Board
4. Compression Tray Board
5. Compression Thickness
Potentiometer
6. Compression Timing Belt
7. Compression Chain
Figure 6-17: Compression Device Components
