LORAD AFFINITY Series - Table 7-2 Gantry Left and Right-Side Components-Parts List

7-2 P/N 9-500-0255
Service Manual
Chapter 7: Parts List
Instructions
Table 7-2: Gantry Left and Right-Side Components—Parts List
Part Number Description Fig.#/Item # Refer To
3-000-5074 Assy, High Voltage Generator Figure 6-1/#3 Chapter 6, Section 2.4.1
1-003-0445 Assy, Power Control PCB Figure 6-1/#4 Chapter 6, Section 2.4.2
1-003-0489 Assy, Auxiliary Power Distribution PCB Figure 6-1/#5 Chapter 6, Section 2.4.3
1-003-0493 Assy, Host Microprocessor Bd Figure 6-1/#6 Chapter 6, Section 2.5.1
1-003-0434 Assy, Communications Interface Bd Figure 6-1/#7 Chapter 6, Section 2.5.3
1-451-5037 Power Supply, Open Frame
(Low Voltage Power Supply)
Figure 6-1/#8 Chapter 6, Section 2.5.4
1-003-0440 Assy, C-Arm Safety Microprocessor Bd Figure 6-1/#9 Chapter 6, Section 2.5.5
Table 7-3: C-Arm Frame Components—Parts List
Part Number Description Fig.#/Item # Refer To
3-405-7071 Patient Face Shield Figure 6-15/#7 Chapter 6, Section 3.1.1
1-003-0289 Assy, Filament Protect PCB Figure 6-15/#2 Chapter 6, Section 3.1.3
3-000-5029 Assy, Top Cover 3 Position Switch Figure 6-20/#2 Chapter 6, Section 3.1.2
1-092-0028 Keyboard, Membrane 1x3 Figure 6-15/#3 Chapter 6, Section 3.1.4
1-092-0024 Keyboard, Membrane 2x3 Upper Left Figure 6-15/#4 Chapter 6, Section 3.1.5
1-092-0026 Keyboard, Membrane 2x3 Lower Left Figure 6-15/#4 Chapter 6, Section 3.1.5
1-092-0025 Keyboard, Membrane 2x3 Upper Right Figure 6-15/#4 Chapter 6, Section 3.1.5
1-092-0027 Keyboard, Membrane 2x3 Lower Right Figure 6-15/#4 Chapter 6, Section 3.1.5
1-003-0436 Assy, Switch Interface PCB Figure 6-15/#5 Chapter 6, Section 3.1.6
1-003-0095 Assy, MAG Tray Detect PCB
(Assy, C-Arm Accessory Detect PCB)
Figure 6-15/#6 Chapter 6, Section 3.1.7
Table 7-4: C-Arm Tubehead Components—Parts List
Part Number Description Fig.#/Item # Refer To
2-425-0042 X-Ray Tube Varian IM-113 Figure 6-16/#1 Chapter 6, Section 3.2.2
2-425-0043 X-Ray Tube Varian IM-113-B Figure 6-16/#1 Chapter 6, Section 3.2.2
1-003-0403 Assy, Tubehead Control PCB Figure 6-16/#9 Chapter 6, Section 3.2.3
3-000-5056 Assy, Fan, C-Arm Cooling Figure 6-16/#3 Chapter 6, Section 3.2.4
9-400-0268 Kit, Beam Limiting Figure 6-16/#s 4-8 Chapter 6, Section 3.2.5
1-003-0378 Assy, Fixed Aperture Detect Board
(part of Beam Limiting Assy)
Figure 6-16/#4 Chapter 6, Section 3.2.6
3-000-4600 Filter Shifter Assy
(part of Beam Limiting Assy)
Figure 6-16/#5 Chapter 6, Section 3.2.7
3-000-5082 Light Field Lamp Assy
(part of Beam Limiting Assy)
Figure 6-16/#7 Chapter 6, Section 3.2.8
