Appendix A: Specifications
System Specifications
10 cm Contact/Magnification
10 cm Open (Rectangular) Localization
10 cm Perforated Localization
15 cm Contact/Magnification
15 cm Open (Rectangular) Localization
15 cm Perforated Localization
18 x 24 cm Full Field F.A.S.T. Paddles
24 x 30 cm Full Field F.A.S.T. Paddles
Ultrasound Paddle
The chest wall edge of the compression paddle
does not extend beyond the chest wall edge of
the image receptor by more than 1% of the
SID when tested with the compression paddle
placed above the breast support surface at a
distance equivalent to standard breast thick-
ness. The shadow of the vertical edge of the
compression paddle is not visible on the
image.
1.8 Apertures
There are six apertures for all combinations of paddles and receptors.
Auto Aperture
7.5 cm Spot Contact
7.5 cm Spot Magnification
10 cm Coned
Magnification Full Field
Stereo Aperture
1.9 Magnification
Magnification Factor 1.8X (2.25 cm above the surface) for platform
and table devices
Material of breast support surface
Platform: Polycarbonate
Table: Carbon Fiber
Size of breast support surface 12 x 16.5 cm minimum to provide full 18 x 24
cm full field magnification at 1.8X.
