A-6 P/N 9-500-0255
Service Manual
Appendix A: Specifications
System Specifications
1.10 Image Receptor Support Device
Image Receptor Support Device Contains sensors for accessory detection and a
3-cell automatic exposure control detector,
movable to seven positions in 1.7 cm incre-
ments. The Image Receptor Support Device
limits x-ray transmission to no more than 0.1
mR for the maximum exposure. Complies with
21 CFR, section 1020.31, and meets the 1
mGy per exposure as defined by IEC 601-1-3,
section 29.207.2.
1.11 C-arm Functions
All C-arm functions Vertical drive, rotation, compression function,
compression release, light field, etc., are
simultaneously operable. Compression up and
down are also controlled by footswitches.
1.12 X-ray Source, Filtration and Collimation
X-ray Tube Varian Integral M113 series or equivalent
Focal Spot Size Per IEC 336-Measurement of X-ray tube focal
spots
Large—0.3 mm, nominal
Small—0.1 mm, nominal
Tube Voltage 20 kV to 39 kV
Tube Current (High speed operation)
Large focus—100 mA minimum between 25
kV and 32 kV
Small focus—30 mA minimum between 25 kV
and 32 kV
Thermal Characteristics
Anode Heat Storage Capacity—210 kJ (300
kHU)
Maximum Anode Heat Dissipation Rate—60
kHU/min
Housing Heat Storage Capacity—370 kJ (500
kHU)
Maximum Housing Heat Dissipation Rate—
100 Watts (135 HU/s) free air convection
Anode Rotation High speed operation (9600 rpm minimum)
Anode Angle Large Focus: 16° target angle
Small Focus: 10
°
target angle
Anode Material Molybdenum
X-ray Window Beryllium, 0.8 mm thickness max.
Maximum Temperature, Tube Housing Surface
85° C (185° F)
Maximum Temperature, Tubehead Cover Surface
41° C (105° F)
