LORAD AFFINITY Series - Chapter 7: Parts List; Instructions; The Replacement Parts Lists

P/N 9-500-0255 7-1
Service Manual
Chapter 7: Parts List
Instructions
Chapter 7: Parts List
1.0 Instructions
This Chapter of the manual provides tabular listings of the serviceable components for the
Affinity. Part numbers and descriptions are provided for component identification.
1.1 The Replacement Parts Lists
The Affinity Parts Lists are:
• Table 7-1: Gantry Cover, Control Panel and Internal Components—Parts Lis t
• Table 7-2: Gantry Left and Right-Side Components—Parts List
• Table 7-4: C-Arm Tubehead Components—Parts List
• Table 7-5: C-Arm Compression Device Components—Parts List
• Table 7-6: C-Arm Image Receptor Support Device—Parts List
• Table 7-7: Miscellaneous—Parts List (Lists accessories, optional equipment, tools and
supplies required.)
The replacement parts lists are divided into four parts as follows:
• Part Number: this is the order number for the part. The L
ORAD Service Department will
require this number when placing an order.
• Description: identifies the part by name.
• Figure #/Item #: identifies the Figure within the Service Manual that shows the compo-
nent location within the system. The Item number is given when applicable.
• Refer To: identifies the Chapter and Section within the Service Manual to go to for instal-
lation or remove and replace procedures for that part.
Table 7-1: Gantry Cover, Control Panel and Internal Components—Parts List
Part Number Description Fig.#/Item # Refer To
1-003-0360 Assy, C-Arm Angle Display Figure 6-1/#1 Chapter 6, Section 2.2.1
1-700-0107 Assy, Emergency OFF Switch Figure 6-1/#2 Chapter 6, Section 2.2.2
3-000-5071 Assy, Power Distribution Figure 6-3/#3 Chapter 6, Section 2.1.4
3-000-5058 Assy, Control Unit Figure 6-6 Chapter 6, Section 2.3
1-003-0428 Assy, Display Microprocessor PCB
(part of Control Panel, Figure 6-1/#13)
Figure 6-6/#1 Chapter 6, Section 2.3.1
1-510-0022 LCD Display
(part of Control Panel, Figure 6-1/#13)
Figure 6-6/#1 Chapter 6, Section 2.3.2
1-070-5026 Circuit Breaker Dual 20A 25 Figure 6-1/#10 Chapter 6, Section 2.6.1
1-700-0018 C-Arm Angle Detent Microswitch Figure 6-1/#11 Chapter 6, Section 2.6.2
1-195-3058 C-Arm Rotation Potentiometer
(Potentiometer WW 10 T 5 K Ohm)
Figure 6-1/#12 Chapter 6, Section 2.6.3
2-230-4002 Belt, Timing 3/32 x 32 Pitch Figure 6-12 Chapter 6, Section 2.6.3
3-000-5072 Assy, Actuator Figure 6-1/#13 Chapter 6, Section 2.6.4
