LORAD AFFINITY Series - Chapter 6: Maintenance-Remove and Replace Procedures; Introduction

P/N 9-500-0255 6-1
Service Manual
Chapter 6: Maintenance—Remove and Replace Procedures
Introduction
Chapter 6: Maintenance—Remove and Replace
Procedures
1.0 Introduction
This chapter details the remove and replace procedures for the Affinity. Where necessary,
references are given for performing required alignment and/or adjustment procedures.
• Section 2.0 provides the remove and replace procedures for the compo-
nents within the Gantry.
• Section 3.0 provides the remove and replace procedures for the compo-
nents within the C-arm Assembly.
Only L
ORAD-authorized, trained service engineers can service this mammography system.
The unit is designed for module-level repair. When a defective module (assembly) is
identified, the technician replaces it with a new one.
Warning: Service engineers must take appropriate radiation safety measures
when testing (or maintaining) the unit.
Caution: Always observe Electrostatic Discharge (ESD) precautions when working
with electronics and electronic components.
Note… When servicing the Affinity, if a procedure instructs you to remove any
covers or panels, do not replace the covers until all required procedures
(e.g., calibrations, adjustments, tests, remove and replace, etc.) are
completed.
2.0 Gantry Components—Remove and Replace
This section provides procedures for performing the following:
• Removing covers and panels from the Gantry, Section 2.1
• Servicing the Gantry cover components, Section 2.2
• Servicing the Control Panel components, Section 2.3
• Servicing the left-side Gantry components, Section 2.4
• Servicing right-side Gantry components, Section 2.5
• Servicing internal Gantry components, Section 2.6
Refer to Figure 6-1 for identification of the Affinity Series Gantry Components.
