LORAD AFFINITY Series - Table 7-5 C-Arm Compression Device Components-Parts List

P/N 9-500-0255 7-3
Service Manual
Chapter 7: Parts List
Instructions
1-080-0008 Lamp
(Replacement lamp for Light Field Lamp
Assy)
N/A Chapter 6, Section 3.2.9
3-000-3230 Assy, Lamp Fan
(part of Light Field Lamp Assy)
Figure 6-30/#4 Chapter 6, Section 3.2.10
3-000-5081 Assy, Motorized Mirror Figure 6-16/#8 Chapter 6, Section 3.2.11
Table 7-4: C-Arm Tubehead Components—Parts List
Part Number Description Fig.#/Item # Refer To
Table 7-5: C-Arm Compression Device Components—Parts List
Part Number Description Fig.#/Item # Refer To
3-000-5067 Assy, Compression Motor Brake Figure 6-17/#1 Chapter 6, Section 3.3.2
See Below Assy, Compression Clutch and Clutch
Brake
Figure 6-17/#2 Chapter 6, Section 3.3.3
3-460-0055 Shaft, Clutch Figure 6-34/#1 Chapter 6, Section 3.3.3
4-000-0132 Assy, Brake Magnet and Suppr Figure 6-34/#2 Chapter 6, Section 3.3.3
2-480-0525 Spacer Round 12 x .75 LG Figure 6-34/#3 Chapter 6, Section 3.3.3
2-155-0006 Clutch, Slip, Comp Dev Figure 6-34/#4 Chapter 6, Section 3.3.3
3-251-0026 Compression Knob (Qty 2) Figure 6-34/#5 Chapter 6, Section 3.3.3
1-003-0472 Assy, AEC Pos. Comp. Display Bd (right) Figure 6-17/#3 Chapter 6, Section 3.3.4
1-003-0473 Assy, AEC Pos. Comp. Display Bd (left) Figure 6-17/#3 Chapter 6, Section 3.3.4
1-003-0103 Assy, Comp. Tray Sensor PCB Figure 6-17/#4 Chapter 6, Section 3.3.5
1-195-3058 Compression Thickness Potentiometer
(Potentiometer WW 10 T 5 K Ohm)
Figure 6-17/#5 Chapter 6, Section 3.3.6
3-230-4002 Belt, Timing, 24 inch Figure 6-17/#6 Chapter 6, Section 3.3.6
Table 7-6: C-Arm Image Receptor Support Device—Parts List
Part Number Description Fig.#/Item # Refer To
3-000-5069 Assy, AEC Detector Figure 6-18/#1 Chapter 6, Section 3.4.2
1-003-0364 Assy, AEC Position Detect PCB Figure 6-18/#2 Chapter 6, Section 3.4.3
1-003-0365 Assy, AEC Accessory Detect PCB Figure 6-18/#3 Chapter 6, Section 3.4.4
1-003-0471 Assy, AEC Position Microprocessor Bd Figure 6-18/#4 Chapter 6, Section 3.4.5
