LORAD AFFINITY Series - Table 4-3 Filament Waveforms Amplitude

4-14 P/N 9-500-0255
Service Manual
Chapter 4: Calibrations and Performance Checks
Exposure System Calibration
Table 4-3: Filament Waveforms Amplitude
Large Focal Spot
(Mo)
Large Focal Spot
(Rh)
Small Focal Spot (Mo) Small Focal Spot (Rh)
kV ma Results mA Results ma Results mA Results
20 kV 75 --- 20 ---
21 kV 80 --- 22 ---
22 kV 85 --- 24 ---
23 kV 90 --- 26 ---
24 kV 95 --- 28 ---
25 kV 100 --- 30 ---
26 kV 100 --- 30 ---
27 kV 100 --- 30 ---
28 kV 100 100 30 30
29 kV 100 100 30 30
30 kV 100 100 30 30
31 kV 100 100 30 30
32 kV 100 100 30 30
33 kV 85 85 28 28
34 kV 80 80 28 28
35 kV 80 80 26 26
36 kV --- 75 --- 26
37 kV --- 75 --- 26
38 kV --- 70 --- 24
39 kV --- 70 --- 24
