LORAD AFFINITY Series - Table B-20 Affinity Series Fuses

B-10 P/N 9-500-0255
Service Manual
Appendix B: Technical References
Fuses
Table B-20: Affinity Series Fuses
Fuse Location—Board Part Number Ref. Des. Description Part Number
Relay Protection Board—1-003-0490 F1 15 A 600 V FB 1-070-1114
Auxiliary Power Distribution Board—1-003-
0489
F11, F20 2 AG SLO-BLOW, 3 A 1-070-1248
F16 CER MDA SB, 12 A 1-070-1327
F18, F19 SLO BLOW, 2 A, 250 V 1-070-1072
F14 2 AG SLO-BLOW, 0.50 A 1-070-1242
F1 - F4 2 AG SLO-BLOW, 5 A 1-070-1251
F5, F6, F10,
F12, F13
2 AG SLO-BLOW, 7 A 1-070-1252
F8 8 A Ceramic Body 1-070-1126
F9 3 AG SLO-BLOW, 7 A 250 V 1-070-1273
F7 CER MDA SB 15 A 1-070-1328
Communications Interface Board—
1-003-0434
F2 - F15 2 AG SLO-BLOW, 1 A 1-070-1244
F1 2 AG SLO-BLOW, 2 A 1-070-1246
HV Generator Assembly—3-000-5074 F1
Power Control Board—1-003-0445 F6 2 AG SLO-BLOW, 2 A 1-070-1246
F2 2 AG SLO-BLOW, 3 A 1-070-1248
F4 2 AG SLO-BLOW, 5 A 1-070-1251
F1, F5 2 AG SLO-BLOW, 7 A 1-070-1252
F3 SLO-BLOW, 10 A 32 V 1-070-1084
