P/N 9-500-0255 A-1
Service Manual
Appendix A: Specifications
System Specifications
Appendix A: Specifications
1.0 System Specifications
The following section details the system specifications.
1.1 Electrical Input Specifications
Mains Voltage 200 VAC, 208 VAC, 220 VAC, 230 VAC, or
240 VAC nominal (±10% tap selectable at
installation), 50 or 60 Hz, 1 phase with sepa-
rate neutral and ground, permanently con-
nected
Mains Impedance Maximum line impedance not to exceed 0.20
Ohms for 200 VAC input voltage, and 0.25
Ohms for all other specified input voltages
Max. Power Consumption 7.75 kVA for 5 seconds duration
Maximum Standby Power 0.5 kVA nominal
Maximum Line Current 35 Amps for 5 seconds
Circuit Breaker Rating 20 Amps. Time delay curve allows for inrush
currents (200% overload for 7 seconds).
Maximum Cycle Rate Full load 5 seconds ON; 20 +
1.5 seconds OFF
1.2 Unit Measurements
Height 178 cm ±2.0 cm (70 inches)
Width 67 cm ±2.0 cm (26.4 inches)
Depth 109 cm ±2.0 cm (43 inches) including C-arm
Weight 267.2 kg ±10 kg (588 lb)
