2-10 P/N 9-500-0255
Service Manual
Chapter 2: System Installation
Unit Installation
3.6.3 Connecting Film Labeling Devices
The Affinity will accept the following film labeling devices:
• AutoFilm I.D.
• Label Printer
The AutoFilm I.D. is used to place photographic labels directly on the film. The
Label Printer is used to create self-adhesive labels that are manually placed on each
film.
Note… The film labeling device (AutoFilm I.D. or Printer) must be installed so that it
is situated at least 2 meters (approximately 6 feet) from the patient.
AutoFilm I.D.
Refer to the AutoFilm I.D. User’s Guide (PN 9-500-0078) for installation and
operating procedures.
Label Printer
The Label Printer is used to print out a self-adhesive label containing the exposure
information. When connected and on-line, the Printer immediately prints a label
after each exposure.
1. Insert the one end of the Printer cable into the receptacle on the rear of the
Printer.
2. Connect the other end of the printer cable to the Printer receptacle (Figure 2-6,
Item 2) on the rear of the Gantry.
3. Plug the Printer power cord into the power receptacle on the rear of the Printer,
then plug the opposite end into the Printer Power outlet (Figure 2-6, Item 4) on
the rear of the Gantry.
3.7 Initial Start Up Procedures
At this point in the Affinity Series Mammography System installation procedures, the unit
should be permanently mounted in position with all power and applicable accessory
connections made (except for radiation shield). The rear panels should all be installed with
the exception of the rear connector panel shroud and the left and right cover panels.
3.7.1 Remote X-ray ON Light Configuration
When installed, the remote X-ray ON light can be configured to define whether it
will be ON only during the X-ray period or throughout the entire boost and X-ray
periods. Configure it as follows:
1. Locate the Host Microprocessor board on the Gantry right side (cover previ-
ously removed). Refer to Chapter 6, Figure 6-1 for board location and identifica-
tion.
2. Install jumper on JP7 as follows:
• For light ON only during X-ray period, install jumper between positions 1 and 2.
• For light ON during Boost and X-ray period, install jumper between positions 2
and 3.
