LORAD AFFINITY Series - Table 3-1 Post Power-Up Checks

3-4 P/N 9-500-0255
Service Manual
Chapter 3: Functional Checks/Setting Defaults
System Power Up
Table 3-1: Post Power-Up Checks
Functional Check Button Procedure
C-Arm Controls—
Perform this test for
each of the four 7-but-
ton keypads on the C-
arm.
1. Light Field Lamp
(Figure 3-2, Item 1)
A. Press and release the Light Field Lamp
button.
B. Verify light field lamp illuminates and
then extinguishes after approximately
30 sec.
2. Compression Down
(Figure 3-2, Item 2)
A. Press and hold the Compression Down
button.
B. Verify the light field lamp illuminates
and the compression device moves
down while button is held.
C. Verify the compression thickness
readout changes accordingly.
D. Ensure compression device stops
when button is released and brake is
engaged (won’t easily move
manually).
3. Compression Release
(Figure 3-2, Item 5)
A. Press and release the Compression
Release button.
B. Verify the compression device moves
up and stops automatically.
C. Verify the compression brakes release
(handwheel turns easily in both
directions).
4. Compression Up
(Figure 3-2, Item 6)
A. Verify the compression device moves
up when the Compression Up button
is held and stops when the button is
released.
B. Apply slight upward pressure to the
Compression Device. Verify the force
readout changes.
5. C-arm Down
(Figure 3-2, Item 3)
A. Verify C-arm moves down while
button is held and stops when button
is released.
6. C-arm Up
(Figure 3-2, Item 7)
B. Verify C-arm moves up while button is
held and stops when button is
released.
