Service Manual
Chapter 7: Parts List
Instructions
Table 7-7: Miscellaneous—Parts List
Part Number Description Fig.#/Item # Refer To
8-005-0007 AutoFilm I.D. N/A AutoFilm I.D. User’sGuide
(PN 9-500-0078)
9-400-0273 Exposure Footswitch Figure 3-1/#3 Chapter 2, Section 3.6.1
3-000-5020 Assy, Footswitch, Dual Function Figure 1-2/#13 Chapter 2, Section 3.6.2
9-400-0242 Kit, Operator Shield Figure 1-2/#12 Chapter 2, Section 3.8.1
3-405-8010 Template, Light/X-ray Field Figure 4-10 Chapter 4, Section 7.1
9-060-0403 Tool, Affinity Image Receptor Phantom N/A Chapter 4, Section 7.4
9-060-0173 Tool, Light Field Alignment Bars N/A Chapter 4, Section 7.10
9-061-0107 Tool, Field Service Belt Adj. N/A Chapter 4, Section 8.2
2-580-0506 Loctite, 242 Blue N/A Chapter 4, Section 8.2
3-000-5083 Aperture, Auto Figure 4-12/#1 Chapter 4, Section 7.3
3-000-5086 Aperture, 7.5 cm Spot Contact Figure 4-12/#2 Chapter 4, Section 7.3
3-000-5088 Aperture, 10 cm Coned-down Contact Figure 4-12/#3 Chapter 4, Section 7.3
3-000-5087 Aperture, 7.5 cm Spot Magnification Figure 4-12/#4 Chapter 4, Section 7.3
3-000-5085 Aperture, Mag Full Field Figure 4-12/#5 Chapter 4, Section 7.3
3-000-3121 Bucky, 18 x 24 cm
Front Load Cassette Holder
N/A N/A
4-000-0241 Bucky, 18 x 24 cm HTC Bucky N/A N/A
4-000-0242 Bucky, 18 x 24 cm SRL 2000 Grid System N/A N/A
4-000-0243 Bucky, 24 x 30 cm HTC Bucky N/A N/A
4-000-0244 Bucky, 24 x 30 cm SRL 2000 Grid System N/A N/A
3-000-4571 Paddle, 24 x 30 cm Standard N/A N/A
3-000-4572 Paddle, 18 x 24 cm Standard N/A N/A
3-000-4579 Paddle, 10 cm Contact/Magnification N/A N/A
3-000-4580 Paddle, 10 cm Perforated Localization N/A N/A
3-000-4581 Paddle, 15 cm Perforated Localization N/A N/A
3-000-4582 Paddle, 15 cm Contact/Magnification N/A N/A
3-000-4583 Paddle, 7.5 cm Spot Contact/Magnification N/A N/A
3-000-4584 Paddle, 10 cm Localization Open N/A N/A
3-000-4585 Paddle, 15 cm Localization Open N/A N/A
3-000-4603 Paddle, 24 x 30 cm FAST N/A N/A
3-000-4604 Paddle, 18 x 24 cm FAST N/A N/A
3-000-5080 Paddle, Ultrasound N/A N/A
3-000-5091 Table, Magnification N/A N/A
3-000-4594 Platform, Magnification N/A N/A
9-400-0236 Kit, Cables, Printer N/A Chapter 2, Section
9-400-0278 Kit, Control Panel, Remote Figure 2-5 Chapter 2, Section 3.4.2
