LORAD AFFINITY Series - Page 16

x P/N 9-500-0255
Service Manual
List of Tables
Table B-18 HV Control Filament Board (PN 1-003-0485) LED Indicators .................................... B-8
Table B-19 Image Receptor Sensor Combinations ....................................................................... B-8
Table B-20 Affinity Series Fuses ................................................................................................ B-10
Table B-21 Microprocessor Board (PN 1-003-0493) Jumper Settings ......................................... B-11
Table B-22 Communications Interface Board (PN 1-003-0434) Jumper Settings ........................ B-11
Table B-23 C-Arm Safety Board (PN 1-003-0440) Jumper Settings ............................................. B-11
Table B-24 HV Control Filament Board (PN 1-003-0485) Jumper Settings ................................. B-12
