P/N 9-500-0255 2-3
Service Manual
Chapter 2: System Installation
Unpacking Instructions
2. Carefully remove all shipping materials (foam padding, tie-downs, straps, shipping wrap,
etc.) from the unit and pallet. Lift any accessory boxes from the pallet.
3. Open all crates and boxes and check their contents against the packing list and sales
order.
Note… If there is a discrepancy between the contents and the packing list or sales
order, contact L
ORAD immediately. If it is necessary to re-pack any items for
future installation, use the original packaging materials.
4. Inspect each item for damage, then safely store them near the exam site.
Caution:
To prevent damage, do not store the radiation shield flat. Avoid damaging
the Radiation Shield by impact or scratching.
Notes… If shipping damage is of a concealed nature, contact the carrier as soon as
such damage is found, and request an inspection for shipping damage.
Normally, any claims for shipping damage must be completed within 15
days of receiving the shipment.
Warning: Never pull on the C-arm as the unit is top heavy. To prevent injury
to personnel and/or damage to equipment, care must be taken
when un-crating the unit.
5. While still in the loading area, carefully move the pallet into an upright position.
6. Remove the top collar securing the unit to the pallet. Using the installed dolly, carefully
roll the unit off the pallet.
7. Transport the unit, on the installed dolly, from the loading area to the exam area for
installation.
8. Remove the 4 bolts securing the unit to the dolly. Carefully maneuver the unit off the
back end of the dolly, slide the dolly out and position the unit in the area of installation.
9. Return the dolly to L
ORAD as per the shipping instructions posted on the dolly.
