2-32
Issue 9 October 1998
363-206-204
Equipment and Rear Access Cable Installation
Procedure
The fan shelf alarm output should be connected to the DDM-2000 OC-3 shelf
located below the fan shelf. The connection can be made in one of the two ways:
a. If no other environmental alarm inputs are being connected to the
DDM-2000 OC-3 shelf, connect a G375 cable between the connector on
the fan shelf alarm cable and P62 on the rear of the DDM-2000 OC-3 shelf.
b. If other environmental alarm inputs, in addition to the fan shelf alarm, are
being connected to the DDM-2000 OC-3 shelf, connect a G376 cable via a
miscellaneous terminal strip to the appropriate wires on the G369 or G370
miscellaneous (environmental) discrete cable in accordance with informa-
tion provided in the job specification. Refer to Table 2-12, 2-16 and to the
"Miscellaneous (Environmental) Discrete Telemetry Cable Installation".
Final Operations
Procedure
1. Verify that all the cables are properly dressed.
2. Verify that all cables are properly labeled.
3. Verify that designations where cables were wire-wrapped are properly
labeled.
4. Attach the backplane cover and make sure that it fits properly.
To Next Page
