Issue 9 October 1998
9-1
Lucent Technologies
9
Release 13 (TARP) Installation Tests
Overview
This section provides test procedures for verifying the following on Release 13
configured DDM-2000 OC-3 shelves:
â–
Shelf transmission
â–
Wiring to DS1 cross-connect (DSX-1)
â–
Wiring to DS3/EC-1 cross-connect (DSX-3) or DACS IV-2000
â–
Fiber Installation and System Test.
â–
For the IAO LAN features, after installation of shelf, refer to 363-206-285,
DDM-2000 OC-3 Multiplexer User/Service Manual
.
Description
The following information provides instructions on the use of an American
Standard Code for Information Interchange (ASCII) terminal and the suggested
installation tests which should be performed. If problems are encountered, refer to
the "Troubleshooting" section at the end of this manual. For detailed
troubleshooting, refer to 363-206-285,
DDM-2000 OC-3 Multiplexer User/Service
Manual
.
The installation tests verify transmission through the shelf, wiring to the cross-
connect (or DACS IV-2000), fiber installation and end-to-end transmission as
shown in Figure 9-1.
The following installation tests are run only in an out-of-service mode of operation.
Interruption of service will result if these tests are run on an operating in-service
system.
