Lucent Technologies DDM-2000 OC-3 Installation Manual

2-34
Issue 9 October 1998
363-206-204
Equipment and Rear Access Cable Installation
† Use two (2) cables.
‡ Use one of each.
Table 2-2. DS3/EC-1 Cable Assemblies
Description
(Note 1)
Old Cable
ED8C727-20
Group
New Cable
ED8C900-20 Group
****
Cable
Length (ft.)
(Note 2)
Cable Type
(Note 3)
Other End
Connector
(Note 4)
T0 DSX-3 or
FT-2000, OC-48*
100 G103 F/E 6BB, 6LA 150 1735006A
KS-23558,L6 BNC
101 G105 ( ) F/E 6BB,
6LA
250 (max.)
103 †G3 F/E AB, LA 150 735A
104 †G5 ( ) F/E AB, LA 250 (max.)
106 Do not use. 150 KS-19224, L2 KS-23558,L4 BNC
107 Do not use. 150 (max.)
109 †G305 ( ) F/E DBD,
1LA
450 (max.) 734A/735A KS-23558,L5 BNC
110 †G305 ( ) F/E DB,
1LA
450 (max.) 734A
To DACS III-
2000
120 G103 F/E 6BC, 6LB 150 1735006A
9821AE
121 G105 ( ) F/E 6BC,
6LB
500 (max.)
123 †G3 F/E AC, LB 150 735A
124 †G5 ( ) F/E AC, LB 500 (max.)
126 †G305 ( ) F/E DBD,
LCD
900 (max.) 734A/735A **
To DACS IV-
2000
130 G103 F/E 6BJ, 6LB 150 1735006A
9821EA &
9821FA
131 G105 ( ) F/E 6BJ,
6LB
500 (max.)
133 ‡G3 F/E AD, LB,
and
G3 F/E AE, LB
150 735A
134 ‡G5 ( ) F/E AD, LB
and
G5 ( ) F/E AE, LB
500 (max.)
136 ‡G305 ( ) F/E DBD,
LDD
and
G305 ( ) F/E DBD,
LED
900 (max.) 734A/735A ***
