Lucent Technologies DDM-2000 OC-3 - Figure 3-7. Side Mounting Bracket Positions (Contd)

363-206-204
Equipment and Front Access Cable Installation
Issue 9 October 1998
3-41
Figure 3-7. Side Mounting Bracket Positions (Contd)
THE SHELF BRACKET CAN BE INSTALLED IN ANY OF THREE DIFFERENT POSITIONS
ED-8C500
REAR MOUNT
CONFIGURATION
(AS SHIPPED FROM
FACTORY)
ED-8C501
FRONT MOUNT
CONFIGURATION
PART OF
BAY UPRIGHT
ED-8C500
FRONT MOUNT
CONFIGURATION
ED-8C500
REAR MOUNT
CONFIGURATION
(AS SHIPPED FROM
FACTORY)
ED-8C500
FRONT MOUNT
CONFIGURATION
ED-8C501
FRONT MOUNT
CONFIGURATION
