363-206-204

Equipment and Rear Access Cable Installation

Issue 9 October 1998

2-49

Table 2-20. IAO LAN Connector Pin Identification - Opposite End (RJ45 type)

Note: Pins 4, 5, 7 and 8 are not used.

Pin No. Color Function

1 White on Orange XQ3P

2 Orange on White XQ3N

3 White on Black RQ3P

6 Black on White RQ3N
