2-60
Issue 9 October 1998
363-206-204
Equipment and Rear Access Cable Installation
Figure 2-10. DS3/EC-1 Cable (KS-19224, L2) Termination
Drip Loop
3 Inch
Cable
219N Splice
Cable
KS-19224, L2
734A
Terminating
Equipment
BNC
