3-12
Issue 9 October 1998
363-206-204
Equipment and Front Access Cable Installation
Procedure
1. Install the interbay DS1 cables (Table 3-1) and connect them to the front
access DS1 cables.
2. Route the DS1 cables out of the bay, stacking cables as shown in Figure
3-2.
!
CAUTION:
The DS1 cables are required to have a minimum length of 30 feet.
3. Remove the slack and cut the cables to the desired length at the DSX-1.
4. Tie cables to the bay cable brackets.
5. Referring to Table 3-5, carefully observe color codes and wire-wrap the
cables at the DSX-1.
DS3/EC-1 Cable Installation -Front
Access
Description
The DS3/EC-1 front access interbay cables are installed (if required) in the same
manner as the DS3/EC-1 rear access cables, except that they connect to the front
access cables instead of the backplane.
Follow the "DS3/EC-1 Cable Installation - Rear Access" in the "Equipment and
Rear Access Cable Installation" section (see note). The cables should be routed
out of the bay, stacking the cables as shown in Figure 3-2.
NOTE
:
Cables to the BBG19 DS3 circuit pack will be connected to the front of the
circuit pack after circuit pack installation.
NOTE
:
Where the procedure states "connect to backplane" the connection should
be made to the "front access cables" instead, which in turn is connected to
the backplane.
