2-46
Issue 9 October 1998
363-206-204
Equipment and Rear Access Cable Installation
Notes
:
1. Refer to the appropriate procedure for the timing connections.
2. The DS1 timing cable is 22 gauge.
Note
: The order wire interface cable is 26 gauge.
Table 2-14. DS1 Timing Reference Connections
Name Design Conn. Term Color
Received from Primary DS1 Reference T
R
P37,
P237,
P44
6
1
BK
O
Received from Secondary DS1 Reference T
R
7
2
R
G
Table 2-15. Order wire Interface Connections
Name Design Conn. Term Color
Received Data RDAO
RCKO
P51 1
6
BL-W
W-BL
Transmitted Data TDAO
TCKO
2
7
O-W
W-O
Ground GND 3 G
Table 2-16. Fan Shelf Alarm Connections
Term inal
Wire
Color
Fan Shelf Connector
Designation
4 BL-W TLM-14
5 BR-W TLM-OC
8 W-BL -48VRT
To Next Page
