363-206-204
Troubleshooting
Issue 9 October 1998
11-7
Table 11-1. BBF8 HDSL I/O Connections
Name Pin No. Function Name Pin No. Function
DSX01T 209 PSXI3T 113
DSX01R 208 PSXI3R 112
DSX02T 207 PSXI4T 111 DS1 Protection
DSX02R 206 PSXI4R 110
DSX03T 205 TVTCSP 316
DSX03R 204 TVTCSN 315
DSX04T 203 HDSL Interface TVTFMS 313
DSX04R 202 TVTDAS 311
DSXI1T 217 RVTCSP 016 VT-G Signals
DSXI1R 216 RVTCSN 017 (Service)
DSXI2T 215 RVTFMS 014
DSXI2R 214 RVTDAS 013
DSXI3T 213 DC52SP 118
DSXI3R 212 DC52SN 018
DSXI4T 211 TVTCPP 317
DSXI4R 210 TVTCPN 318
PSX01T 109 TVTFMP 312
PSX01R 108 TVTDAP 310
PSX02T 107 RVTCPP 319 VT-G Signals
PSX02R 106 RVTCPN 218 (Protection)
PSX03T 105 RVTFMP 015
PSX03R 104 RVTDAP 012
PSX04T 103 DS1 Protection DC52PP 119
PSX04R 102 DC52PN 019
PSXI1T 117 LSICKP 307
PSXI1R 116 LSICKN 306 Control
PSXI2T 115 LSICDP 010
PSXI2R 114
To Next Page
