Lucent Technologies DDM-2000 OC-3 - Figure 8-3. 27 G-U OLIU

363-206-204
Releases 9 and 11 Installation Tests
Issue 9 October 1998
8-31
Figure 8-3. 27G-U OLIU
27G-U
S1:1
Fault
Lucent
Active
OLIU
2
IN
OUT
1
2
IN
OUT
1
OC-1 #2
Associated with the 2nd STS-1
OC-1 #1
Associated with the 1st STS-1
