363-206-204
Powering, Verification, and Circuit Pack Installation
Issue 9 October 1998
4-17
Download Procedure
NOTE
:
Refer to the "Install New Generic Program" (DLP-532) of 363-206-202
(Releases 6 and 7), 363-206-280 (Releases 8, 9 and 11) and 363-206-285
(Release 13),
DDM-2000 OC-3 Multiplexer, User/Service Manual
while
performing the following procedure. If unfamiliar with the operation of the
PC, refer to the "Introduction to the PC" (DLP-533) of any of these
DDM-2000 OC-3 Multiplexer, User/Service Manuals.
1. With the PC
not
connected to the DDM-2000 OC-3 shelf, insert the first
diskette into the PC.
2. Use the appropriate MS-DOS command (for example, a: or b:) to go to the
drive where the diskette is inserted.
3. Enter the term command. Observe the message that is printed. Verify that
the PC is set for the same baud rate as the BBG5 circuit pack. The mes-
sage gives the user the choice to continue or not continue with the down-
load procedure. If the user chooses to continue, observe the following
response:
CTRM ready. (Type Alt-h for help.)
Communications established
4. Connect the PC to the CIT connector on the front of the shelf user panel.
5. Press the RETURN (or ENTER) key on the PC (press twice for Releases 8,
9, 11 and 13).
Response:
/*Enter a shelf number from 1 to 8*/
shelf [default]=
6. Again press the RETURN (or ENTER) key.
Response:
In Progress .....
NOTE
:
A series of dots following the ‘In Progress’ will continue while the software
is downloaded. A prompt will be displayed when the next diskette is
required.
7. Remove the existing diskette and insert the next diskette.
After the completion of the software download, a message
ins-prog: TID
COMPLD
will appear.
8. For Releases 7.2, 8, 9 and 11, an AGNE alarm will exist upon completion of
the download. To extinguish this alarm, set the AGNE to yes by using the
set-ne command.
