To reduce the possibility of ESD damage, assemblies are equipped with
grounding jacks to enable personnel to ground themselves using wrist straps (see
Figure 1) while handling circuit packs or working on an assembly(s). The jacks for
connection of wrist straps are located at the lower right-hand corner of each
assembly and are labeled. When grounding jacks are not provided, an alligator
clip adapter enables connection to bay frame ground.
Figure 1. Static Control Wrist Strap
Ground
To
Connection
