Lucent Technologies DDM-2000 OC-3 Installation Manual

363-206-204
Equipment and Front Access Cable Installation
Issue 9 October 1998
3-5
Inspection
Description
Perform the following procedure before the DDM-2000 OC-3 Multiplexer
installation or cable installation.
Procedure
1. Verify that the frame or structure into which the DDM-2000 OC-3 will be
installed is properly grounded.
NOTE
:
Each DDM-2000 OC-3 shelf, heat baffle, and fan shelf (when provided)
comes with an installation kit, a pouch attached to the shelf, baffle, or fan
shelf, containing the hardware required for mounting and grounding. The
installation kit for the baffle and fan shelf has the following contents:
The installation kit for the DDM-2000 OC-3 shelf has the following:
The installation kit for the fan shelf has the following:
Quantity Description
4 0.216-24 x 5/16" Thread Cutting Screws (C803535012)
Quantity Description
4 0.216-24 x 5/16" Screws (C803535012)
2 Fuses and Fuse Caps
2 26 Gauge Cable Clamps
1 ED-8C724-20 G378 Termination
Quantity Description
4 0.216-24 x 5/16" Screws (C803535012)
6 Cable Ties
1 Taptite Screw
1 Grounding Cable
