3-28
Issue 9 October 1998
363-206-204
Equipment and Front Access Cable Installation
NOTE
:
Parallel telemetry is not available in Release 13 software.
Note
:
1. Cable lengths listed, as required, are specified by the customer.
2. All cables are part of ED-8C724-21 and they connect to a front access cable, not to the
backplane.
3. All cables are 26 gauge.
Table 3-4. Telemetry and Modem Cable Assemblies
Description
ED-8C724-21
Group
Cable Length
(ft.) (Notes 1, 2
&3)
DDM-2000 Backplane
Connections
Parallel Telemetry-
For Bottom Shelf (See NOTE
below.)
437 150 P254
of Front Access Cable
438 As Reqd.
Office Alarms-
For Lowest Shelf
439 150 P56
of Front Access Cable
440 As Reqd.
Misc. (Env.) Discrete Telemetry-
1 per Shelf
441 150 P261 (at CO)
P62 (at RT)
of Front Access Cable
442 As Reqd.
Fan Alarm Interface cable 457 2 J262 of Front Access
460 150 Wire wrap to
terminal strip
461 As Reqd.
To Next Page
