363-206-204
Equipment and Front Access Cable Installation
Issue 9 October 1998
3-27
NOTE
:
Parallel telemetry is not available in Release 13 software.
NOTE
:
TBOS is not available in Release 13 software.
Note
:
The "one cable connector" end connects to its mate on the DDM-2000 OC-3 backplane
(that is, P37 on the G414 cable connects to J37 on the backplane).
* This cable is for future applications.
** This cable does not connect to the backplane. It is used to connect the CIT and modem
mult between shelves that are not of the same TBOS link.
Table 3-3. Front Access Mult Cable Assemblies
Description
ED-8C724-21
Group
Cable
Length
One Cable
Connector
(Note)
Other
Connector
DS1 Timing Mult. 415 2 ft. 3 in. P44 P237
Q2 In Mult* 418 3 ft. 6 in. P50 P251
Parallel Telemetry Mult. (See
NOTE below.)
422 3 ft. 1 in. J55 J254
Office Alarms Mult. 424 3 ft. 1 in. J57 J256
TBOS Mult. 425 2 ft. 5 in. P58 J258/J258A
TBOS Mult. 426 2 ft. 5 in. P60 P258/P258A
Mult without TBOS** 427 5 iin. P258A J258A
To Next Page
