Lucent Technologies DDM-2000 OC-3 - Figure 2-4. Connector Pinouts

363-206-204
Equipment and Rear Access Cable Installation
Issue 9 October 1998
2-53
Note:
Terminals are numbered by looking at the connector from the wiring side.
Figure 2-4. Connector Pinouts
B1
21
A8
A1
24 Pin Unshielded
5
1
25 Pin Shielded
25
13
9 Pin Shielded
9
6
B8
14
1
2423
DS1 Cable Connector
14
13
14 Pin Unshielded
1 2
